CNC Steel Bar Stirrup Bending Machine

The CNC Steel Bar Stirrup Bending Machine automatically completes the processes of rebar straightening, length setting, bending, and cutting. It is a professional piece of equipment for efficiently producing rebars of various shapes. The wire feeding section consists of two sets of automatically adjustable horizontal and vertical straightening wheels, ensuring high precision in rebar straightening. The bending section is driven by a servo motor, and the bending arm can quickly rotate and extend/retract. The shearing mechanism starts immediately upon receiving a signal and completes the shearing action, ensuring the precision of the formed material. The perfect combination of rebar straightening, length setting, bending, and cutting meets the precision requirements of rebar processing, truly achieving multi-purpose functionality. It saves time, labor, and materials, offers high processing precision and high production efficiency, and enables fully automatic, uninterrupted assembly line rebar processing operations.

Feature

1. Precise CNC Forming

Equipped with a high-performance CNC system, the bending angle (0-180°), stirrup size, and hook length can be digitally set, with a processing error of ≤±0.3°, ensuring uniform stirrup dimensions.

2. Fully Automated Process

Integrates the entire process of rebar feeding, straightening, bending, cutting, and forming, eliminating the need for manual segmented operation and achieving continuous, integrated processing of stirrups.

3. Extremely High Processing Efficiency

Compared to traditional manual stirrup bending, efficiency is increased by 6-10 times. A single machine can process thousands of stirrups per day, adapting to large-scale production needs.

4. Wide Range of Compatible Specifications

Supports processing of Φ6-16mm round steel and threaded steel. Rectangular, circular, diamond, and irregular stirrup shapes can be customized to meet various engineering design requirements.

5. Simple and Convenient Operation

Equipped with a visual touch interface, it features multiple preset templates for commonly used stirrups, supports parameter storage and retrieval, and allows beginners to quickly get started without professional training.

6. Extremely Low Material Waste

Through precise feeding and cutting control, stirrup cuts are clean and waste-free, increasing material utilization by 8%-12% and reducing consumable costs.

7. Intelligent Data Management

Supports production counting and parameter traceability. Some models can connect to engineering management systems for real-time monitoring of processing data, meeting standardized construction requirements.

8. Stable and Durable Operation

The machine body uses a high-strength steel structure, key components are made of wear-resistant materials, and it features an automatic lubrication system, resulting in a low failure rate and long service life during continuous operation.

9. Comprehensive Safety Protection

Equipped with an emergency stop button, anti-pinch device, protective cover, and other multiple safety interlocks, it reduces operational risks and complies with safety production regulations.

10. Highly Flexible Processing

Supports customizable stirrup sizes and shapes, allowing for quick switching between different specifications of processing tasks without frequent equipment adjustments, adapting to multiple batches of small-volume production.

11. Compact footprint: The optimized layout design results in a compact structure that does not occupy too much space, making it suitable for installation in temporary processing areas on construction sites or fixed workstations in factories.
