RJG1500 / RJG2200 / RJG2500 Steel Cage Roller Welding Machine

The RJG series is an intelligent rebar cage rolling welder for bored piles. It feeds main bars and winding wire automatically and welds them into a finished steel cage — round, straight and evenly spaced — while a crew of 3–6 workers loads bars and unloads finished cages. A shift produces 8–15 cage sections.

Three models cover the full pile range. The RJG1500 handles pile diameters from Ø600 to Ø1500 mm, the RJG2200 from Ø800 to Ø2200 mm and the RJG2500 from Ø1000 to Ø2500 mm. All three make cages 12 m long as standard, customisable to 15, 18, 21 or 25 m. Main bars run Φ12–32 mm and winding bars Φ6–16 mm, with stirrup spacing adjustable from 50 to 500 mm. Total power is 15–25 kW and the footprint is 30 × 6 × 2 m.

These machines suit bridge foundations, metro stations, high-rise pile foundations and precast pile plants — anywhere bored piles are made in volume. Compared with manual cage tying, a rolling welder keeps the cage round, the spacing even and the output steady across a whole shift, and it cuts the labour on each cage to a small crew. Send your pile diameter and cage drawing and we will reply with the right model and a quotation within 24 hours. WhatsApp: +86 13465772392.

WS42 CNC Steel Bar Bending Center

CNC rebar cage rolling machines are core automated equipment for processing rebar cages in infrastructure projects such as bridges, high-speed railways, and subways, focusing on efficient forming and standardized production.

Equipped with a CNC system and dual servo drive mechanisms, the equipment can automatically complete the entire process of main bar feeding, stirrup winding, weld point positioning, and cutting and forming, eliminating the need for tedious manual binding. Parameters such as rebar cage diameter, length, and stirrup spacing are digitally adjustable, with errors controlled to the millimeter level, ensuring component consistency.

Compared to traditional manual methods, processing efficiency is increased by 3-5 times, significantly reducing rebar waste and labor costs. It can also process main bars of Φ12-40mm and stirrups of Φ6-12mm, and supports customized round and irregular-shaped rebar cages. The machine body uses a high-strength steel structure, is equipped with a safety guard and a visual operating interface, and operates stably and conveniently. It is a key piece of equipment for achieving large-scale and precise rebar cage processing in modern infrastructure projects.

Feature

1. Stable Quality: Mechanized operation is unaffected by human factors, ensuring stable quality even after long-term operation.

2. High Speed: 3-6 people can normally produce 10-20 rebar cages per day.

3. Suitable for various design requirements regarding the quantity, form, model, size, and length of main reinforcing bars and ribs; the machine's functionality will not affect the rebar cage design or prevent its production.

4. Low Power Consumption: Total power is 15KW, with less than 5KW used during synchronous operation, saving energy and not affecting the overall capacitor ratio.

5. Convenient Transportation: The modular design allows for handling, installation, and production without relying on lifting equipment, adapting to both large-scale fixed production in factories and mobile operations in dispersed construction sites.

6. Threaded connection technology enables precise positioning, helping to improve the speed of rebar cage disassembly and installation.

7. Assembly line approach: Independent construction is unaffected by individual processes, allowing for uninterrupted completion of the entire process, including main reinforcement estimation and welding, and reinforcement wrapping welding.
